DSL-2640UEOL EOS
תאור
ULTIMATE INTERNET CONNECTION
The DSL-2640U wireless ADSL router is an affordable high-performance ADSL router for home and the small office. With integrated ADSL2+ supporting up to 24Mbps download speed, 802.11g wireless LAN, firewall protection, Quality of Service (QoS) and 4-port switch, this router provides all the essentials that a home or small office needs to establish a secure and high-speed remote link to the outside world.
AFFORDABLE HIGH-SPEED CONNECTION FOR HOME & SMALL OFFICE
Designed as a very affordable high-performance ADSL router for home and SOHO users, the DSL-2640U provides not only the low-cost, high-speed Internet connection, but also the security and Quality of Service (QoS) required by users in today’s high-risk and versatile Internet environments.
READY WIRED & WIRELESS LAN CONNECTION
The DSL-2640U provides an integrated 802.11g WLAN interface supporting wireless speeds of up to 54Mbps and interoperability with 802.11b wireless devices on the 2.4GHz frequency band. It also provides four 10/100Mbps Ethernet switch ports for ready workstations connection. These built-in functions save you the cost and trouble of installing a separate wireless access point and an Ethernet switch.
FIREWALL PROTECTION & QoS
Security features prevents unauthorized access to the home and office network from Internet intruders. The router provides firewall security using Stateful Packet Inspection (SPI) and Denial of Service (DoS) attack protection. SPI inspects the contents of all incoming packet headers before deciding what packets are allowed to pass through. Router access control is provided with packet filtering based on port and source/destination MAC/IP addresses. For Quality of Service (QoS), the router supports multiple priority queues to enable a group of home or office users to experience the benefit of smooth network connection of inbound and outbound data without concern of traffic congestion. This QoS support allows users to enjoy high ADSL transmission for applications such as VoIP, streaming multimedia and on-line games over the Internet.
מאפיינים כללים
Interfaces
• ADSL: 1 port with RJ-11
• LAN: 4 ports 10/100BASE-TX Ethernet with RJ-45 connector with auto MDI / MDIX cross
• WLAN: built-in wireless interface standard, 802.11b, g and n draft
Wireless Network
• Standard IEEE 802.11n, compatible with current standard IEEE 802.11b / g
• Support for guest wireless network
• WEP-encryption
• WPA/WPA2 encryption technology with the mechanisms of TKIP, AES and TKIP + AES
• Access to a wireless network based on the MAC-address
• PIN and PBC methods WPS function
• Advanced Settings
ADSL standards
• ADSL: multi-mode, ANSI T1.413 Issue 2, ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A, ITU-T G.994.1 (G . hs)
• ADSL2: ITU-T G.992.3 (G.dmt.bis) Annex A / L / M, ITU-T G.992.4 (G.lite.bis) Annex A
• ADSL2 +: ITU-T G.992.5 Annex A / L / M
Types of WAN-connection
ADSL:
• PPPoA
• PPPoE
• IPoE
• IPoA
• Bridge
Ethernet:
• Static IP
• DHCP
• PPPoE
Minutes of ATM / PPP
• Encapsulation of Ethernet in bridge and router
• Multiplexing-based VC / LLC
• ATM Forum UNI3.1/4.0 PVC (up to 8 PVC)
• ATM Adaptation Layer Type 5 (AAL5)
• The principles and functions of OAM ITU-T I.610, including F4/F5 loopback
• ATM QoS
• PPP over ATM (RFC 2,364)
• PPP over Ethernet (PPPoE)
• Support for Keep-alive for PPP-protocol
Network Protocols and Features
• Static IP-routing
• The mechanism of NAT
• DHCP-server/klient/relay
• DNS relay
• Dynamic DNS (DDNS)
• UPnP
• VLAN support
• IGMP proxy
Firewall and Access Control
• NAT firewall
• Monitor status of network connections (SPI)
• Filtering by MAC-addresses from the time of day and day of the week
• URL-filter
• Packet filtering (IP / ICMP / TCP / UDP)
• Virtual Servers
• Prevent DoS-attacks
• Intrusion detection and logging
• Technology to protect DMZ
• Supports Port Triggering
QoS
• grouping of interfaces
• 3 priority queues
Configuring and Managing
• Web-based configuration and management in multiple languages
• Update the router's internal software via web-interface
• Save and load configuration
• Support for remote logging
• SNMP-agent
• Automatic synchronization of system time from NTP-server
