D-View 6.0EOL EOS
תאור
The D-View® 6.0 SNMP Network Management System is a software tool that facilitates the central administration of a network with various SNMP-enabled devices. The D-View 6.0 Professional version (DV-600P) is tailored for networks with more than 1000 nodes.The D-View 6.0 Professional version (DV-600P) also provides a server-based architecture that simplifies the daily management of the network. Flexible and versatile, D-View 6.0 provides network management to SNMP-based devices, including third party devices.
Automatic Discovery of Network Devices
Administrators can create a topology diagram to graphically represent planned or existing networks with a simple click of a button. Through SNMP or ICMP, a topology is automatically generated from your network devices. Traps can be sent to remote network devices to obtain status information. D-View 6.0 can recognize a device’s standard (SNMP or non-SNMP), type (router or switch, wired or wireless) and network domain. That’s only the beginning of the types of analyses administrators can perform on all their network devices. Import a bitmap of your building’s blueprint and display your network’s topology on top of the blueprint to provide a realistic representation of the network topology.
Batch Configuration or Firmware Upgrades
D-View 6.0 makes switch firmware upgrades and configuration changes easier. Simply select the network devices you wish to upgrade and, with the click of one button, upload your software. This feature is especially useful in setting up a network. It is also useful for maintenance, as a group of switches can be scheduled for the same services: rebooting, port status monitoring, or enabling such features as Spanning Tree or the D-Link® Safeguard Engine™.
MIB Browser/Compiler/Utilities
D-View 6.0 supports third-party devices as well. With the D-View MIB compiler, an administrator can compile and load third-party MIB files into D-View. In this recognizable format, D-View can then communicate with the third party devices making them manageable through D-View. Valuable information can then be polled to provide a complete status of the switch. Even in environments with products from mixed vendors, D-View can still provide a unified management platform.
Network Status – Real Time Management
D-View 6.0 is a useful tool for monitoring network status and performance in real time. It allows trap and alarm notification to be set, and can notify the administrator via e-mail. With the Event Viewer, Filter Setting can extract the exact information needed by event (type or severity), time (all or specific period), device (vendor or type), and source. Trap Log and Filter can be set to facilitate troubleshooting and monitoring.
D-View 6.0 can also present network performance in colorful bars and graphs, displaying easy-to-read charts with percentage of packet flow, types of packets, port flow, and much more, any time you want.
Microsoft SQL Server/Access Format Database
Completely integrate managed devices into your network environment with MIB support. With the MIB compiler and network topology data organized according to the Microsoft SQL Server and Microsoft Access formats, you’ll have the option of editing their database using D-View, Microsoft SQL Server, or Microsoft Access software.
מאפיינים כללים
System requirements for the standard version of the D-View6.0
• CPU - 1,4 GHz and above
• DRAM 1GB and above
• Free space on your hard disk: 200 MB (at least for system files D-View, not including space needed for the database to Microsoft SQL-professional version)
• Ethernet NIC 10/100/1000 Mbit / s
Software Requirements
• Internet browser Internet Explorer 6.0 and above Microsoft XML Parser and SDK
Operating System Requirements
• Microsoft Windows 2000 Server (English version) with Service Pack 4
• Microsoft Windows 2000 Advanced Server (English version) with Service Pack 4
• Microsoft Windows 2003 Server (English version) with Service Pack 2
• Microsoft Windows XP / Home / Professional with Service Pack 2 (only for the standard version)
Database management system (only professional version)
• Microsoft SQL Server 2000 (English version) with Service Pack 2
• Microsoft SQL Server 2005 (English version)
Topology Management
• Visual representation of the topology of Microsoft SQL Server 2005 (English version)
• Import / Export topology to / from XML-file
• Domain Manager
• Channel Manager
• Web-based client
• Automatic topology discovery
Management errors / events
• Trap Editor
• Trap Filter
• Event Configuration
• Polling Configuration
• System Log
• Syslog Server
Device control
• Setting up a group of devices (Batch Configuration):
• Save a file
• Enable / Disable RMON
• Enable / disable Safeguard Engine
• Software Update
• Update on Resource device
• Updating the configuration file
• Updating the configuration file
• Check the port status
• Reboot the selected devices
• Device Manager
• MIB-compiler / MIB-browser
• MIB Utilities
• Surveillance for Windows Server
Resource management
• Determination of devices: the search for devices by IP-address and an indication of its position on the map topology
• Displays statistics of devices: the vendors, the buyers and the date of purchase
• Performance Monitoring: collecting information on devices RMON, report to the three parameters (the ratio of errors (Error ratio), the distribution of data (Data distribution), the flow through the port (Port Flow)).
• Monitoring packets on a port:
• Gathering information for devices that do not support RMON
• Gathering statistics on the basis of RFC1213
• Support for two reports: the use of the port and package information
Security Management
• Authentication: a local database and an external RADIUS server
• Differentiated management of users
• Security SNMP v.3
System management functions
• System Configuration
• Administrator Manager
• Checking the channel capacity
• Check the type of device
• Checking the status of the Safeguard Engine
• Trace Route
